Hydropam

Industry 2b
DN Lu
m		 Angular
Deflection		 PFA
bar		 PFA
bar		 PFA
bar		 PFA
bar		 PFA
bar		 PFA
bar
60 6,00 5 c40 64 k9 85 k10 85 k11 100 k12 * k13 *
80 6,00 5 64 85 85 100 * *
100 6,00 5 64 85 85 100 * *
125 6,00 5 64 85 85 100 * *
150 6,00 5 62 79 85 97 100 100
200 6,00 5 50 62 71 80 90 99
250 6,00 5 43 54 61 70 78 86
300 6,00 5 40 49 56 63 70 78
350 6,00 4 c30 35 k9 45 k10 51 *k11 58 *k12 65 *k13 71
400 6,00 4 32 42 48 55 61 67
450 6,00 4 30 40 45 52 57 63
500 6,00 4 30 38 44 49 55 60
600 6,00 4 30 36 41 46 51 56
700 6,96 4 – k9 34 k10 38 *k11 43 *k12 48 *k13 53
800 6,95 4 32 36 41 46 50
900 6,95 4 31 35 40 44 48
1 000 6,96 4* 30 34 38 43 47
1 100 8,19 4 29 32 37 41
1 200 8,19 4 28 32 37 41
1 400 8,17 3 28 31 35 39
1 500 8,16 1 27 30
1 600 8,16 3 27 30
1 800 8,15 2,5 27 30
2 000 8,13 2 26 29

PFA = Allowable operating pressure

Please refer to next section «design safety factor» for pressure definitions.

* = Please consult Technoroi
